Specifications:
- Double walled outside made of Mild Steel exterior epoxy powder coated paint.
- Inside chamber made of Stainless Steel.
- Temperature range of the chamber is ambient plus 5 ° C to 90 ° C .
- Temperature controlled by Microprocessed PID controller having 4 ramp & 4 soak profile having set mode, alarm parameter, configuration parameter, profile parameter, set point profile, Pv error indicator , parameter for locking etc with Pt 100 sensor.
- This chamber will have air circulation fan to ensure uniformity of temperature.
- A carrier to hold bottles (6 no. of 60mm Dia x 200mm Depth) can be easily placed on front of rotater Mechanism any bottle can be taken out easily from the carrier.
- The carrier rotates with bottles parrelel to the door at a variable speed of 2 to 16 RPM. Veiwing glass window in the door allows inspection of the specimen inside the chamber.
- Alarm:It is possible to provide electronic alarm, if temperature deviates more than ± 5 °C to cost extra
