Uses:

• Seed Testing

• Biological Studies

• Veterinary Science

• Forestry Research

• Pathology


Construction: This is double walled cabinet insulated with 75 mm by puff. between interior and exterior walls.  Outer chamber made of mild steel and furnished in durable white enamel paint.  The inner chamber made of anodized aluminium with shelf supports allowing wide range of shelf positions and spacing.

Dimension of Each Working Chamber

Height 910 mm x Width 555 mm x Depth 605 mm

Each chamber has 14 trays.  Totally 28 multi perforated aluminium trays of size 430 x 480 MM each all having 57500 SQ-CM-approx. of testing area.  The distance between the tray is 4 CM.  Both chamber have full view acrylic door which allows inspections of sample without disturbing temp. of working chamber.  Outer double walled metal door with lock and key.  A push type switch for illumination lamp is provided in each chamber of inspection of the samples during high condensation cabinet is mounted on caster.

Water Reservoir For Humidity:-Each chamber has stainless steel water reservoir at the bottom and water is heated by low wattage immersion heater which assures to maintain.  The humidity from 90 to 95% +/- 3% ( non- adjustable) and to be maintained at this level. Humidity shall be controlled by Micro processed temp. & RH controller temp. accuracy± 1 °C & RH Accuracy ± 5 °C . Each water reservoir has constant water level arrangement with two no. brass nozzle, one for inlet and other for outlet and a brass drain plug is also provided.

Temperature:- Temp. in both chambers is controlled by a Digital temperature indicator cum controller from in the variation of plus minus 1 deg.c. at any temp. between 5 to 60 deg,c at normal ambient temp. in which chamber is fitted with refrigeration system.  In the other chamber, temp. can be maintained from few deg. Above ambient to 50 deg.c.   The cooling chamber is provided with a selected switch to operate the unit either above or below ambient temp. desired.

Cooling System:-One chamber has cooling system by a heavy duty sealed compressor with all accessories and also a fan cooled condensor are fitted at the bottom exactly below the working chamber.  Copper cooling coil is fitted at the back of inside chamber.

Air Circulating:-Each chamber has separate air circulation by FH Motor with ample provision for an even distribution of air by a fan which assures uniformity of temp. throughout the chamber.

Control Panel:-Control Panel is given at the top of chamber having ON-OFF switch three indicators for main cooling and heating , temp. setting knob which is graduated in the centigrade from 5 to 50 deg.c volt meter in cooling chamber prismatic Digital Temp. Indicator graduated from 0-50 deg.c., to work on 220/230 Volt 50 cycles A.C only.

Optional Arrangements:-

SGA-1      Width 555 mm x Depth 605 mm x Height 910 mm 308 Lt rs.

SGA-2      Specifications as above but provided with heating & cooling in both the

                  chambers from 5 deg.c.  To 50 deg.c in both chamber  instead of one for

                  heating and another one for cooling.

SGA-3      Interior chamber & shelves made of stainless steel

                  In both the chambers instead of anodized Aluminium shall cost Extra.

SGA-4      Seed Germinator with two sides lighting arrangement & two nos.  0-24 hour

                  timer at an extra cost

Alarm:It is possible to provide electronic alarm if, temperature deviates more than ± 2 °C and RH ± 5% to cost extra.
