LAMINAR AIR FLOW BENCH (HORIZONTAL)
Product Details:
This complete package unit is provided to give clean air to any laboratory. Useful where any hyper criticalwork has to be performed within minimum contamination as they assure 99.97% removal of airborne particles as 0-3 microns in the work area. The basic elements are pre-filters, heavy duty blower assembly; HEPA (high Efficiency particular Air) filter (Absolute filter) fresh air is drawn through the pre-filter and passes to absolute HEPA filter. Ultra clean air moves horizontally in Laminar flow bench cross the work area at a velocity of approximate 90; ± 20 feet per minute.
CONSTRUCTION :
Basic material is Duro board wood front back top and exterior surfaces are covered with Formica, All interior surfaces are epoxy painted filter seat is carefully formed, installed and checked for leakage. Work table is made of Mica top and side panels are made of 6 mm thick glass transparent framed in anodized Aluminum angle frame. Blowers are fitted with 1/4 H.P. Electric Motor operates with minimum noise and vibration. Suitable to Work on Single Phase 220 / 230 volts A.C. supply.
TECHNICAL SPECIFICATIONS & ORDERING INFORMATIONS
Working Table Size | 2' x 2' | 3' x 2' | 4' x 2' | 6' x 2' |
Working Size | 2' x 2' x 2' | 3' x 2' x 2' | 4' x 2' x 2' | 6' x 2' x 2' |
HEPA Filter Size | 2' x 2' x 6" | 3' x 2' x 6 | 4' x 2' x 6" | 3' x 2' x 6" |
No. of Motor/Blower | 1 | 1 | 1 | 2 |
Illumination | 1 x 20 w | 1 x 20 w | 2 x 40 w | 2 x 40 w |
Main Filter | HEPA Filter (99.97% efficient at 0.3 micron particles) | |||
Pre-Filter | High efficiency pre-filter (Washable) | |||
Sterilization | By U.V. Germicidal Tube in work area | |||
Front Door | Made of Plexi Glass 6 mm | |||
Noise Level | Less than 65 db | |||
Standard Accessory | Gas/Air cock | |||
Electric Supply | AC 230V , 50/60Hz |
