| Pressure Generation : | Direct via Ram Screw | | Standard Parameters : | Gravity: 9.80665 m/s²
Temperature: 23º C
Air Density: 1.2 kg/m³ | | Weight : | 20 kg for base machine | | Operating Fluid : | Di-Octyl Sebacate (DOS) | | Piston Material : | Tungsten Carbide | | Internals MOC : | Mainly SS, Brass, Aluminum | | Weights : | Austenitic Stainless Steel |
| | Overall Range : | 1-1400 bar | | No. of Pistons : | Two (Dual Piston Type) | | Low Pressure Range : | 1-70 bar | | High Pressure Range : | 20-1400 bar | | Accuracy : | 0.008% of rdg. | | Standard Accessories : | Set of Weights in Carry Box
Set of adaptors: (1/8", 1/4", 3/4", 1/2") BSP
Instruction Manual
Set of Spare Seals
Calibration certificate as per quotation 1/2 liter of operating fluid
Oil temperature sensor
Displacement sensor system
Fractional masses for fine readings
Piping for cross floatation
Constant volume valve
Hydraulic pump for generating pressure
|
|
Yantrika Instruments Pvt. Ltd.
