Refrigerated Water Bath

Product Details :

Refrigerated Water Bath has a double walled construction, outer made of mild steel and inner chamber made of stainless steel sheet. Controlled by digital temperature controller with glass window for observation. Heating is achieved by immersion type heater temperature from 0°C to 90°C.

Advantages & Benefits:

• A compact refrigerated/heating circulator
• Eliminates the hassles of using a separate heating Bath & a separate Chiller
• Built-in circulator pump for efficient circulating processes
• It offers highest level of performance, flexibility and control for the most demanding applications
• Low noise level
• Wide operating ranges and applications
• Constructional Features
• Inner bath chamber & lid made of stainless steel (SS-304 grade)
• Outer body made of CRC sheet duly powder coated
• Space between inner and outer chamber filled with high grade PUF insulation for minimal thermal losses
• High Condensation efficiency
• Adjustable working temperature ranges available
• Environment friendly CFC FREE refrigerants and hermetically sealed compressor used
• Reduces tap water consumption thus reducing the high cost of water and wastewater.
• Waste water does not contain hazardous substances thus eliminating danger to personnel and environment caused by solvents

Model Overview:

• Tighter cooling control for reduced energy consumptions
• Temperature Control accuracy of ±0.5°C at -10°C
• Internal circulation enables precise temperature stability/uniformity in the bath better than 0.5°C
• Temperature Display Resolution 0.1°C
• Powerful stirring circulation pumps with 15 Lpm capacities at zero head for water
• Do not use water below 5°C (use ethanol below 5°C)
• Do not use water above 90°C (use silicone oils etc above 90°C)
• To work on 220/230 volts, 50/60 Hz AC Supply

Additional Information:

• Item Code: LBS-RWB-191
