UV-2230 UV/Vis Detector


  • Working Potential: 190nm – 650nm
  • Wavelength Precision:         ≤ ± 0.1nm
  • Wavelength accuracy:         ≤ ± 0.3nm
  • Optical bandwidth: 6nm
  • Rise Time: 0.0s-9.9s
  • Baseline Noise: <±0.2 × 10-5 AU(empty cell, 254nm, time-60min)
  • Baseline Drift: ≤1×10-4 AU/h (empty cell, 254nm, time-60min)
  • Power: Analytical Flow Cell: Optical path length 10mm: volume 10mL Semi Preparative flow cell: Optical path length 3mm; Volume 5mL
  • Light source:     Deuterium lamp & Tungsten lamp
  • Power: AC 110V/220V, 50Hz/60Hz
  • Consumption: 110W
  • Dimensions: 120mm × 280mm × 175mm
  • GLP SupportGLP Support: Detailed Report with lamp, Operation time, number of lamp, Ignitions and further service
  • Time Constants:         0.1/0.2/0.5/1/2/5/10s Information
