Zonotech ZL-TF High-Temperature Tube Furnace
Product Details :
| Model | BL-TF1150 | BL-TF1450 |
| Maximum Temp. | 1150°C | 1450°C |
| Working Temp. | 1100°C | 1350°C |
| Temp. Accuracy | ±1°C | ±1°C |
| Heating Elements | Kanthal - A1 wire, coil type with end connection, easily replaceable. | Silicon carbide, coil type with end connection, easily replaceable. |
| Inner Chamber | Ceramic Refractory/Board with heating elements placed on the top and bottom. | |
| Insulation | Ceramic Fibre | Ceramic Fibre |
| Construction | Tripple walled with air insulation on the outer side for minimal skin temp. | |
| Body | Made of mild steel duly powder coated. | |
| Tube Material | Alumina(Option-quartz) | |
| Tube Size | Inner Dia.=75 mm /Hot zone length=200 mm /overall length=600 mm ,Furnace with tube of different dia Hot zone length and overall length can also be made as per customer requirement. | |
| Gas Purging | Ends of the tube have Almuniam couplers with cooling attachment for purging of gases | |
| Power control | SSR Unit | Scr Unit(Phase Angle Thyristor) |
| Temp. Control | Microprocessor-based PID Digital set point controller.Dual display of set & actual temp.with soft touch keys with thermocouple break protection and cold junction compensation.CE mark to meet EMC regulation | |
| Sensor | Cr/Al | Pt/Pt - Rh 13% |
| Safety | Over current and short circuit protection.Thermocouple break alarm.High temp alarm. | |
| Power Supply | 220 volts,single phase AC supply. | |
Zonotech ZL-TF High-Temperature Tube Furnace
- Views: 125
-
ZONOTECH INSTRUMENTS - Vendor Type: Manufacturer, Supplier
- Product Code: BL-TF1150
- Availability: In Stock
- ₹0
