The NSW Split Tube Furnace comprise a furnace body which is mounted on vertical stand and is hinged so as to split into two halves along its length.

The free standing vertical design is ideal 900 deg.c  for warp around heating applications such as extension test rings or vertical reaction tubes.  The NSW is also available as a lower temperature version with 900 deg.c maximum operating temperature.  Usually required but does not include an appropriate accessory worktube 2 ½ inch.

Standard Features

• 900 deg.c maximum operating temperature
• heated tube length of 455mm
• furnace split into two halves to accommodate reator vessels, large wrokpieces or samples fixed into a test rig
• suplied in near hinge configuration complete with stand
• over temperature protection from secondary controller

Microprocessed PID controller having 4 ramp & 4 soak profile having set mode, alarm parameter, configuration parameter, profile parameter, set point profile, Pv error indicator, parameter for locking etc.
