Abrasive Cutting Machine Table Top DQS-150 A

Product Details :

ABRASIVE CUTTING MACHINE DQS-150-A

• The machine is designed to meet the requirements of metallurgical parameters for cutting the sample burn less with sufficient amount of coolant flow enabled by 0.25 HP pump.
• This model has dual cutting action; descending action as well as oscillation action. Wheel comes down on the job and simultaneously wheel has oscillation motion. This kind of cutting actions offers
• faster cutting with minimal burning chances due to minimized contact area between wheel and job.
• The machine has fixed as well as flexible coolant veins to direct the coolant throw at the desired location. The machine ensures complete operator safety through enclosed structure and safety features like door open indication, emergency stop, overload protection etc.

Technical Description|Features

1. Motor -15 HP, 3 phase,

2. Coolant Pump - 420 Volt0.25 HP, 3 phase

3. Cutting Capacity - 140 mm solid bar

4. Cutting Action Oscillation and chop type (Auto) - Cutting Action Oscillation and chop type (Auto) Oscillation of wheel is effected by Motorized movement; Chop type movement is effected by electro- hydraulic mechanism

5. Wheel movement- 170 mm along cutting axis

6. Cutting Wheel Accepts - 350 to 500 mm dia wheels; bore 25.4 mm

7. Power Transmission - By V belt

8. Control Panel- Separate panel consisting of On/off button for main motor and pump, Emergency stop, Overload protection.Indicator for door open etc.

9. Sample clamping Sturdy - vice with 6” opening to hold the samples provided on the T- slotted bed.

10. Coolant Recirculation - Equipped with coolant pump, coolant tank (with 2 compartments) mounted on castor wheels, motorized magnetic filtration system etc

Mounting Stand Aesthetic stand with color comprising to the color of the machine and having different storage compartments to store the consumables and spares.
