Abrasion Testing Machine
Product Details:
Los Angeles Abrasion Testing Machine is used for determining the resistance to wear of small size coarse aggregates and crushed rock. The abrasion testing machine consists of a Closed hollow cylindrical steel drum rotating around its horizontal axis on ball bearing units mounted on a sturdy base framework at a speed of between 30-33 rpm. Supplied complete with subtracting revolution counter to preset the number of revolutions, a sample collection tray for removal of the sample on completion of testing and set of 12 abrasive charges.
Specification :
- The los angeles abrasion testing machine is fitted with 1 HP Motor
- Suitable for Operation on 440 V
- Phase: Three Phase, 45Hz, AC Supply
- Speed between 30-33 rpm
Cat No. & Name | Description |
AT-215: Flakiness (Thickness) Gauge | Used for Determination of flakiness index of coarse aggregates. It consists of a steel frame with a sliding panel having slots of different dimensions. |
AT-216: Elongation (Length) Gauge | Used for Determination of elongation index of aggregates. It consists of a steel frame having slots of different dimensions. The frame is fixed on a hard wooden base. |
