Technical Specifications :
- Model – PMT/1000/200/H
- One piece bed made of high grade cast iron casting provided with strong ribs for rigidity and a large inverted prismatic guide and wide track for the table.
- Center height: - 200 mm.
- Swing over table: - 390 mm.
- Admit between center: - 1000 mm.
- Work head swivel: - ± 90°
- Wheel head swivel: - +45°
- Work head speed: - four speed trough step pulley.
- External Grinding wheel size: - Ø 400 x 40 x 127 mm.
- Work head Morse Taper: - MT – 4
- Tail stock Morse Taper: - MT – 4.
- Automatic lubrication on main moveable slide by flow control valve.
- Separate hydraulic power pack unit fitted with 24v D.C Valve but without Enclo – 68 Oil.
- Inbuilt electrical control penal board having all reputed components.
- More rigid and precise Tailstock having 25 mm traverses.
- Manually feed resolution: - 0.005 mm on radius.
- Auto in-feed at table reversal is also available on customer demand.
- Internal Grinding attachment having Dia. 80 / 250 mm ID Spindle with P4 grade matched pair antifriction Bearings of two pairs having 14,000 rpm with dynamic balanced pulley, Endless flat belt with safety guards.
POWER: -
- Wheel head: - 5 hp
- Work head: - 1 hp
- Hydraulic: - 1 hp
- Coolant pump: - 0.16 hp
- Total Power: - 7.16 hp
Automatic Bore Grinding Machine with PLC
- Views: 424
- Vendor: Delight Engineering
- Vendor Type: Manufacturer
- Product Code: PMT0000026
- Availability: In Stock
- ₹0
