Hydraulic Concrete Block Making Machine

Hydraulic Concrete Block Making Machine

Product Details :

Fully equipped with all the latest machines and technologies, our company is the well established manufacturer and exporter of Hydraulic Concrete Block Making Machine. All these machines are installed in the industries for making bulk quantities of concrete blocks used in the pavements. Available in different models, capacities and specifications, these machines are in confirmation with the industry standards and norms. We are offering this Hydraulic Concrete Block Making Machine to our clients at industry leading prices.

Features :

  • Hydraulic operated
  • Egg laying type machine
  • High efficiency with excellent productivity

Hydraulic Machine (860 mm)

We are manufacturing and exporting a wide range of Hydraulic Machine (860 mm). The Hydraulic operated concrete block making machine is egg laying type machine designed by well experienced engineers having 10' years experience. The machine will lay on the floor and move forward. These hydraulic machines are provided with best quality components and are highly durable in nature which provide longer service time.


Specifications :

Model VSV 03
1060 MM Hydraulic Machine
Power
8.5 HP Three Phase Motor
Hydraulic Pump Motor
5 HP 1440 RPM Three Phase
Vibrator Motor
3 HP 2880 RPM Three Phase
Travel Motor
0.5 HP 1440 RPM Three Phase
Operating Pressure
140 kg/cm2
Vibrations
6000 Hz Amplitude Adjustable
Moulding Area
1060 x 600 mm
Dimension
2000 x 1500 x 2000 mm
Weight
1400 kg (Approx)
Production Capacity
4" block 10 block / stroke / 2200 / Shift
6" block 6 block / stroke / 2000 / Shift
8" block 5 block / stroke / 1500 / Shift
Production Capacity Varies with Operator Efficiency
