Consolidation Apparatus
Product Details:
The standard outfit comprises fixed ring type of consolidometer cell for testing specimens 60 mm dia x 20 mm thick, but the unit is so designed that specimens of varying sizes from 50 mm dia to 100 mm dia can also be tested. Besides, the same loading unit can be used with floating ring consolidometer cells, which can be supplied at extra cost. The standard outfit is supplied with a set of weights to give a total pressure of 10 kg/cm2 (besides a seating load of 0.05 kg/cm3 on the specimen), but an additional set of weights are required to reach the full capacity of 20 kg/cm2. The necessary accessories to perform the permeability test of the 'Varying Head' type can also be provided at extra cost. The outfit is also available as three-gang or six-gang in which three/six consolidometers are mounted on a single frame. The consolidation may be measured by the conventional dial gauges or using the transducers and electronic readout unit in Digital Modals.
MILESTONE INSTRUMENTS offers the following models:
Consolidation Apparatus 60mm specimen dia, single gang
Consolidation Apparatus 60mm specimen dia, three gang
Consolidation cell assembly
