Universal Permeability Apparatus
Product Details:

Power Source

Electric

Material

Steel

Finish

Polished

We are the leading Manufacturer of the Universal Permeability Apparatus that is developed as per an IS: 2720 (Part XVII) unit. We manufacture the units as per the specifications of our customers. The units are produced using good quality raw materials for a longer life of the product.


The Apparatus Consists Of The Following

• A gunmetal mould which is 100mm dia. x 127.3mm height x 1000ml volume
• An extension collar 100mm dia. x 60mm high

• Drainage base plate having a recess for a porous stone with an outlet valve
• Metallic clamping ring

• Drainage cap (Top plate with a recess for a porous stone and fitted with an inlet valve and an air release valve)
• Dummy plate to serve as a false bottom curing compaction

• Porous stone for drainage base plate
• Porous stone for drainage cap

• Set of three glass stand pipes in approximate sizes of 6 mm dia., 10mm dia. and 20mm dia. mounted on a stand
• 3 meter long rubber connecting tube with pinch cock.

• Our Universal Permeability is offered with 9 glass tubes on a wooden stand. There is also a provision for an overhead tank which is made of G.I Sheet and also a rammer for above of 2.6 kg. which is available at extra cost.
