PH & Temperature Indicator

Product Details :

• Size 48(w)x48(h)x85(d)mm (Model - WDI-2301-PH)
• Size 72(w)x72(h)x110(d)mm (Model - WDI-2101-PH)
• Size 96(w)x48(h)x110(d)mm (Model - WDI-2001-PH)
• Size 96(w)x96(h)x85(d)mm (Model - WDI-2201-PH)
• Microcontroller based, double display
• Supply 220 V Ac
• Red display for pH indication
• Green display for temperature indication
• pH electrode Input (millivolt) & PT100 type RTD input for temperature
• Temperature 0 to 100.0c
• Manual or auto(Online) selection for temperature compensation.
• Increment key to see millivolt output of pH electrode.
• Password facility for configuration mode to avoid unauthentic entry.
• Open indication in temperature display if PT100 Rtd (Sensor) break.
• Err indication if PT100 Rtd break in pH display
• Led blink in auto mode
• Auto(Online) mode if PT100 sensor connected
• BNC Female connector for pH electrode

Additional Information:

• Item Code: WDI-2XXX-PH
