Dynamic Pass Box

Specifications :

Dynamic Pass Box is a self-contained unit installed at the entrance to clean rooms. They minimize the amount of particulate contamination and is easy to install and adaptable to existing facilities. The pass boxes offered by us are the safest equipment which contain clean zone cross contamination of material in transit. These boxes operate on the principle of one door opening at a time with electromagnetic interlocking so as to avoid any possibility of cross contamination. The unit is supplied with magnetic gauge the pressure drop in the unit while operation Our custom made units are easily installed on the wall between clean room and other room and are made with resistant epoxy-coated steel. With UV Light these are fitted with a mechanical interlock system that prevents both doors from being opened at the same time. ZEXTER offers unmatched prices, usage and application for various pharmaceutical industries.

Construction Details- Our unit has double walled construction is Made up of Stainless Steel

Suction Filter: -

• Filter Casing- S.S.304
• Media- Non-woven synthetic media sandwiched between two layers of High Density
• Supply Filter/ Hepa Filter: -
• Filter Casing- Aluminum factory extruded section.
• Efficiency- 99.97%

Media- Micro fiberglass paper media (Imported) pleated along with Hot Melt Glue

Blower Motor Assembly: - 230 Volts, 50 Hz, Single-phase blower along with inbuilt motor.
