HTHP Yarn Dyeing Machine
HTHP Yarn Dyeing Machine is designed for dyeing of fibers / yarns in production. Capacity of dyeing machine is calculated by the yarn to be dyed. The formula calculated i.e the receipe of the colour which is used to dye the different type of yarns, in Sample Dyeing Machine is used in this H. T. H. P. Yarn Dyeing Machines. H T H P Yarn Dyeing Machines are controlled by programmable controller The Dyeing Vessel available in market are in different forms like Vertical single vessel or Horizontal with no. of small tubes which vary according to the capacity of the yarn to be dyed.
Features :
- Capacity up to 500 kg.
- Reversible TURBO Pump.
- Carriers for cone, hank, tapes etc.
- Air pad or fully flooded versions available.
- Semi automatic facilities.
- PLC assistance also available.
- Very small liquor ratio 1:5 to 1:6
Specification :
| Specifications | |
| Type of Fibers / Fabric | silk, polyester, light weight cotton, wool etc. |
| Maximum working temperature | 140oC. |
| Maximum working pressure | 6 kg/cm2 |
| Heating Rate | 20oC - 130oC approx 30 min (Saturated steam pressure 6 kg/ cm2) |
| Cooling Rate | 130oC - 80oC approx 20 min (Cooling water at 3 kg/cm2) |
| MOC | SS 304 / 316 |
| Capacity | 5kg to 500kg |
| Panel Board | Programmable Semi Automatic |
| Optional | fully automation. |
| Application | Packages, Bobbins, Loose Fiber, Hank Yarn, Beams, Muffs / Tops. |
