Robust and right construction design for all type of bulk sterilization which are commonly required in medical, agriculture and pharmaceutical .  suitable for sterilizing hospital dressing linen , rubber , plastic goods, surgical instruments glass wire etc.

It is based on the principle that any microbiological action of saturated steam elevated temp. in rapid and through.

Construction:

• Triple walled with steam jacket with separate boiler all construction are made up of heavy gauge S.S steel 304 Qlty.  mounted on tubular stainless steel frame with ground leveling screwed flanges. The outer jacket is wrapped with mineral wool to minimize the heat loss.  These sterilizers are hydraulically tested to withstand 2.5 times of working pressure.

• Steam generator is made of heavy gauge stainless steel sheet heavy ring mounted in front of the boiler with folding thick stainless steel plate is fitted with heating element and low water level cut of device to protect with the former from burning out dry.  Pressure control device is fitted in all electrically operated sterilizer.  It cuts of the power supply to heater when the set pressure is activated flange type immersion heating elements are made of high grade material.

Safety Door:

Sterilizer has engaged self-locking single piece thick S.S. plate door and cannot be operated under pressure.  The self locking device automatically disengages the thread mechanism when the sterilizer is under pressure to preclude any eventuality of accident.

Single Point Control:

Complete sterilizing cycle is controlled from on point with the help of “Multiport Valve” fitted at front top.  Two speeds of steam exhaust are available fast and slow.  Easily readable jacket and chamber pressure on gauges mounted on the multiport valve.  A moisture trap is fitted in the chamber discharge  line to absorb the condense automatically to prevent moistening of the subject matter to be sterilized

Safety Features:

The sterilizer is provided with the triple safety features.  At the boiler level by a PIEZOSTAT which automatically limits the pressure to the required set valve and a spring loaded safety valve in case of its failure which releases the steam to keep pressure within the safety limits.  At the chamber level, a spring loaded safety valve and a dead weight release valve to release the steam in case the pressure exceeds the safety limit.  All these safety features function independent of one another failure.

A plug screen prevents the discharge line form choking.  The plug is easily removable for daily cleaning.  Power ejector for drying sterilized line circulates the air throughout the chamber.  The circulating air passes through a corrosion resistant metallic wool filter.  A steam trap is fitted in the chamber discharge line to eliminate the condensate automatically.  Fully Automatic by PID Controller to show the chamber temperature.  Automatic Vacuum breaker is provided to break vacuum due to steam condensation.

• STERILIZING TEMP.                      120 Deg. C.
• STERILIZING PRESSURE             1.2 TO 1.5 KG. (15 PSI TO 22 PSI)
• POWER                                           440 V 3 PHASE 50 HZ A.C. SUPPLY.

SIZE OF INSIDE WORKING CHAMBER

Optional Accessories:

• Thermograph to record sterilizing temp. and time
• Door at back also
