- Usage of Machine : Machine is used for endurance testing various machines Food Industry, Automobile Industries etc.
- Construction:This is double walled cabinet insulated with 125 mm thick puff between interior and exterior walls. Outer chamber made of Mild Steel and painted in Epoxy Powder coating in white color. The inner chamber shall be made of Stainless Steel 304 qty. Outer double walled metal door with MAGNETIC GASKET and lock & key. The chamber will have strong base for fitting your fixture. This chamber shall be supplied with temperature controller. It will incorporate one compressors with all its protective devices along with two fan cooled condensing coil just below the working chamber. This chamber will have air circulating fan from the top of the cabinet. The chamber will have 2” dia hole from one side for feeding cables. Control panel shall be provided at the side of the chamber with three indicators one for main, one for heating, and one for cooling and a digital volt meter. Dual electric digital temp. controller to control temperature from minus 40 °C to + 110 °C +/- 5 °C . Humidity controller (Electronic) with control for dry & RH which will show present value and set value to maintain 95% humidity at 37 °C . this chamber shall work on 440 Volts 3 phase 4 wire system.
- Option: Independent display for temperature & % RH. Self tune PID control loop for temperature & % RH. Heater and humidifier control outputs which will have serial communication port RS 484, 2 wire, half duplex, start - stop synchronized safety standard meets EN-61010 with temperature alarm system
Hot and Cold Chamber
- Views: 412
-
Narang Scientific Works Pvt Ltd - Vendor Type: Manufacturer
- Product Code: NSWR000002
- Availability: In Stock
- ₹0
