Centre Height = 100mm / 150mm / 200mm

Max. Job Length = 200mm

Max. Swing = 300mm

Face feed resolution = 0.002mm by fine feed device.

Wheel Head :

• Grinding spindle = Dia. 60 X 250mm or Dia. 100 X 300mm
• Spindle speed = 9000 to 18000 RPM
• Power = 3 hp, 3 phase, 2800 rpm, AC
• Swivel = - 60 degree

Work head :

• Imported P4 grade matched pair bearings of two pairs.
• Speed = 25 to 500 infinitely variable
• Power = 1 hp , 3 Phase, 1500 RPM, AC
• Morse Taper = MT4
• Swivel = ± 60 degree

Hydraulic :

• Separate hydraulic power pack unit housed outside the machine for easy maintenance.
• All electricals mounted in a separate panel box. Centralized controls for operator’s convenience.
• c. Power = 1 hp , 3 Phase, 1500 RPM, AC
