Occupancy Sensor

Product Details :

Due to state-of-the-art development unit, we are offering an extensive series of Occupancy Sensor. The sensor unit is made to monitor motion within the arena of its activate and view an electrical load. It offers benefits in energy management, safety and security and hospitality. These products are developed as per industry norms employing the premium-grade component and advanced technology. Our products are widely employed due to longer operational life and top performance.

Features:

• LM-80 Certified LED’S
• Certificates:-IP66, LM79, IS10322, IEC61000
• Surge protection >2kV

Parameters:

• Working voltage:200V AC~250V AC
• Load power: 800W
• Working temperature: -10 To 40 Centigrade
• Delay time: 30 to 300S
• Detecting range: ≤10 meter, coning angle 120º
• Light control: less than 10 LUX
• Suggest Installation height: 1.4 to 1.6 meter
• Load: filament lamp; energy saving lamp; daylight lamp; exhaust fan
• Installation: Suction point mounting / ceiling mounting
• Three-wire system.
• Dimension: Diameter: 86 mm/ Thickness: 38 mm
• Color: Porcelain white
