Plate Bearing Test Apparatus

Product Details :

We are one of the leading organizations involved in offering Plate Bearing Test App. Our highly qualified professionals make use of superior quality components for fabricating these instruments. Moreover, these instruments are available in different sizes and specifications for the suitability of the clients. Following are the different components of these instruments:

• Hand operated hydraulic jack along with pressure gauge of capacity 50 tonne with 5 meter long metal tube and an end coupling
• Proper ball and socket arrangement consisting of two steel plate along with a single steel ball in between them.
• Extension rod of 12 mm dia X 25 mm long for taking dial gauge reading
• 4 magnetic base with female thread on top for holding extension rod
• 4 top end plate of 50 mm dia male thread for fitting on the extension rod
• Column 15 cm dia x 50 cm long with flanges that is completed with four bolts and nuts
• Column of 15 cms dia and 50 cms long along with flanges completed with 4 bolts & nuts
• A Datum bar, which is light in weight, portable, total span of 5 meter height approx 30cms and mounted on two removable legs, made up of 2 parts
