CNC Bar Stirrup Bender Gute
Product Details :
Model Name/Number | 12D-2 |
Bending Material | MS or TMT |
Capacity | 5 to 12 mm |
Type | Digital Fully Automatic |
Usage/Application | Stirrups |
Automation Grade | Automatic |
Brand | Gute |
Gross Weight | 3.5 Ton |
Single Wire | 6-12 mm |
Double Wire | 6-12 mm |
Rated Power | 25 Kw |
Power Load | 5 Kw |
Traction Speed | 75-100 m/min |
Max. Bending Speed | 1050 Degree per Second |
Tensile Strength | Kg/mm245 |
MAX. BENDING ANGLE | 180 Degree |
MAX. LENGTH OF STIRRUP SIDE | 900 mm |
MIN. LENGTH OF STIRRUP SIDE | 90 mm |
BENDING DIRECTION | Both |
LCD | Touch Panel |
Coil stand | Double |
Traction Wheel | Hydraulic |
Accessories | With Air Compressor |
We produce kinds of wire straightening and cutting machines, such as wire straightening and cutting machine, stirrup bender and welding machine. Which is R&D by our own factory! Can supply you the best service and technology.
Advantages :
1. We have many experience in CNC machining service
2. We can accept small order for the beginning
3. Sample order can be finished in one week
4. Top quality guaranteed by skilled workers, managing system and status of facilities.
5. We have many long cooperation supplier. supply ONE-STOP service
6. Customized size and spec /OEM.ODM available
7. Our workers are all professional and all can speak ENGLISH
8. 100% inspect before delivery
Wire Bending Machine Cnc
Features (SGW12D-1) :
- Single Wire: 6-12mm
- Double Wire: 6-10mm
- Traction Speed: 75-100m/min
- Max. Bending Speed: 1050º/sec
- Weight:3.5t
