Uses:

• Seed Testing

• Biological Studies

• Veterinary Science

• Forestry Research

• Pathology


Construction:

This is double walled cabinet insulated with 75 mm by puff  between interior and exterior walls.  Outer chamber made of mild steel and furnished in durable white enamel paint.  The inner chamber made of anodized aluminum with shelf supports allowing wide range of shelf positions and spacing.

Dimension of Each Working Chamber

Height 910 mm x width 555 mm x Depth 605 mm

Chamber has 14 trays. The distance between the tray is 4 CM.  chamber have full view acrylic door which allows inspections of sample without disturbing temp. of working chamber.  Outer double walled metal door with lock and key.  A push type switch for illumination lamp is provided in chamber of inspection of the samples during high condensation cabinet is mounted on caster.

Water Reservoir For Humidity:-Chamber has stainless steel water reservoir at the bottom and water is heated by low wattage immersion heater which assures to maintain.  The humidity from 90 to 95% +/- 3% ( non- adjustable) and to be maintained at this level. Humidity shall be controlled by Micro processed temp. & RH controller temp. accuracy± 1 °C & RH Accuracy ± 5 °C. water reservoir has constant water level arrangement with two no. brass nozzle, one for inlet and other for outlet and a brass drain plug is also provided.

Temperature:-Temp. in chambers is controlled by a Digital Indicator Cum Controller from in the variation of plus minus 1 deg.c. at any temp. between 5 to 60 deg,c at normal ambient temp.  The cooling chamber is provided with a selected switch to operate the unit either above or below ambient temp. desired.

Cooling System:-Chamber has cooling system by a heavy duty sealed compressor with all accessories and also a fan cooled condenser are fitted at the bottom exactly below the working chamber.  Copper cooling coil is fitted at the back of inside chamber.

Air Circulating:-Chamber has separate air circulation by FH Motor with ample provision for an even distribution of air by a fan which assures uniformity of temp. throughout the chamber.

Control Panel:-Control Panel is given at the top of chamber having ON-OFF switch three indicators for main cooling and heating , temp. setting knob which is graduated in the centigrade from 5 to 50 deg.c volt meter in cooling chamber prismatic Digital Temp. Indicator graduated from 0-50 deg.c., to work on 220/230 Volt 50 cycles A.C only.

SGA-8D Seed Germinator (Without lighting arrangement) inside made of anodized aluminum.  Dimension of working chamber H.910 x  W.555 x D.605 MM with 14 trays.  Fitted with cooling and heating arrangements.  Temp. from 5 to 50 deg.c +/- 1 deg.c..  Humidity range 90 to 95% plus minus 3%.( non- adjustable) 308 Lt rs.

SGA-8LT Seed Germinator SGA-8D provided with lighting arrangement and 0-24 hours time switch for regulating cyclic illumination condition with electronic digital voltmeter in super deluxe model.

Optional:- Interior chamber and shelf made of stainless steel. 304 Quality can be supplied, instead of Anodized aluminum.

Alarm:It is possible to provide electronic alarm if, temperature deviates more than ± 2 °C and RH ± 5% to cost extra.
