Bosch GOL 32D Optical Auto Level

Product Details:

The Bosch Gol 32D Optical Site Level has been designed for experienced and novice users, with a build quality worth of the Bosch.
Bosch optical levels provide a perfect combination of precision and robustness. Reliable and exact results. Compact metal design suitable for construction sites and tough outdoor conditions.
Every aspect of the Bosch GOL 32D demonstrates how series Bosch is with getting their survey tools designed and built to meet the user’s requirements. The Bosch Site Level GOL 32 D is not just another level. The Site proof casing surrounds the very high-quality 32x magnification optics that offers clear images of the leveling staff over long and short distances. The housing on the Bosch 32D Automatic Level is solid with an easy 360-degree rotation plate with clear precise position marks. The base plate of the site level sits firmly on the Bosch Site tripod included with this kit. The site tripod is strong enough to be loaded used time and time again in all site environments offering a very stable platform for the Site Level. The Bosch 5 Meter leveling staff complements this excellent value package – The Bosch GOL 32 D Optical Site Level.

SPECIFICATION

Technical data: Bosch GOL 32D Professional Level
Model                             Bosch GOL 32D Professional
Unit of measure                         360  degrees
Magnification                           32x
Leveling accuracy                       1 mm at 30 m
Working range                        up to 120 m
Dust and splash protection IP 54
Tripod thread                            5/8″
Operating temperature            -10 – 50 °C
Storage temperature                    -20 – 70 °C
Length                                               215 mm
Width                                               135 mm
Height                                                145 mm
Weight, approx.                                  1.7 kg

FEATURES

Bosch GOL 32D Professional Features:

• Designed for outdoor use due to sturdy metal housing with dust and splash protection (IP54)
• Robust design with built-in target collimator and integrated circular vial

• Compensator lock for safe transport
• Target collimator for rough alignment

• Pentaprism makes it easy to read the circular vial
• Large focusing knob for easy alignment
• Fast aperture for excellent staff reading

• High precision (1.6 mm/30 m) over long distances
• Endless angle setting using knobs on both sides with friction-braked rotation

• Erect image
