Double Display, PID Controller-3 Relay
Product Details
MODEL | PID-4203-1C | UTC-4203 |
Dimension (HxWxD) mm | 48 X 48 X 95 | 48 X 48 X 95 |
Panel Cutout (mm) | 44 X 44 | 44 X 44 |
Display | Upper Display: 7 segment, 4 digit, 0.39" RED LED display-Process value. Lower Display: 7 segment, 4 digit, 0.28" GREEN LED display-Set value | Upper Display: 7 segment, 4 digit, 0.39" RED LED display-Process value. Lower Display: 7 segment, 4 digit, 0.28" GREEN LED display -Ampere |
Sensor | J / K (Configurable) | J / K / PT-100 2W/3W (Configurable) |
Range | J(0 to 600°C), K(0 to 800°C) | J(0 to 600°C), K(0 to 1200°C), PT-100 2W/3W(- 99°C to 400°C,-99.9°C to 400.0°C) |
CT Input | CT MODUAL(3 CT -30 AMP EACH) |
|
Control Output | 3 Relay/SSR/Buzzer | 3 Relay/SSR/Buzzer |
Relay Ratings | 1C/O, 5A, 230V AC | |
SSR/Buzzer | 12V DC approximately | |
Set point | 3 - Set Point | 3 - Set Point |
Control Action | PID/ON-OFF(Configurable) | PID/TP/ON-OFF(Configurable) |
Operating Mode | Relay-1:Heat/Cool/Alarm,Relay-2:Heat/Cool/Alarm,Relay-3:Heat/Cool/Alarm | |
Resolution | 1°C Fix | 1°C For J/K/PT-100,0.1°C FOR PT.1 |
Accuracy | ±1% of FSD | |
Power Supply | 100-250V AC/DC, 50/60 Hz, SMPS | |
Protection | Relay turns OFF in case of sensor break | |
Indication | "OPn" message is displayed if sensor is disconnected & LED for Relay Status Indication | |
Enclosure Material | ABS & Polycarbonate | |
Operating Ambient Temp | 0°C - 55°C | |
Relative Humidity | Upto 95 % RH Non Condensing |
