Shear Test Apparatus
Product Details :
Material | Stainless Steel |
Sampling Tube | 38 mm |
Spring | 2 to 8 kgs/cm Sq |
Diameter | 2 x 5mm |
Consists of a torque head adjustable in height by means of a lead screw rotated by a drive wheel to enable the vane to be lowered into the specimen. Rotation of the vane is by means of a hand wheel which operates a worm gear arrangement turning the upper end of a calibration torsion spring, vane dia, rod dia, vane size & vane height are as per IS specifications. The vane shaft is attached through the hollow upper shaft to a resettable pointer, which indicates the angle indicates the angle of torque on a dial graduated in degree the dial reading multiplied by spring factor.
