Wrapping Testing Machine

Product Details :

Minimum Order Quantity: 1 Piece

Wrapping & Unwrapping Test Apparatus

(For steel wire range 0.2 mm to 9.0 mm)

Model : FWR

Technical Specification :

a. Motorized maximum 60 rpm approx. speed or low can be control by AC drive (if needed differ then please specify)

b. Mandrill 4 no’s

c. Digital revolution indicator

Optional :

i)  AC Drive for variable Speed Controls 0-60 RPM

ii)  Wrapping Test meter (Automatic):

Wrapping test meter, In which required wrap-unwrap revolution has  to be preset (it range is 999 revolution) after which machine will start rotating clockwise & anti clockwise due to which wrapping and wrapping test perform, it will rotate till the number of revolution which is preset is not over

Additional Information :

• Delivery Time: standard
