OCTO Lite 150
Product Details :
The OCTOLite 150 bench top video machine from Quality Vision International (QVI) brings non-contact measurement within reach of virtually any manufacturer, Great for measuring small parts in a small amount of space, OCTOLite 150 offers a long list of standard features.
- Intuitive metrology software Measure-X® metrology software provides an extensive set of functions for general purpose dimensional measurement.
- Superior optics OCTOLite 150 has a sharp-imaging 6.5 to 1 motorized programmable zoom lens. Images stay in focus and on-axis throughout the zoom range.
- Robust staging OCTOLite 150 features precision mechanical bearing XYZ stages with 1.0 pm linear scales. Coaxial coarse/fine XY adjustment knobs and convenient front-mounted Z motion adjustment knobs ease part positioning and focus.
- Image processing OCTOLite 150 features, full field-of-view image processing with advanced strong and weak edge algorithms
- Consistent Z axis measurement Obtain accurate Z measurements and repeatable focus from user to user with the graphical CompuFocus feature
OCTO Measuring Range (mm) | ||
---|---|---|
X | Y | Z |
150 | 75 | 125 |
OCTOLite 200/300
- The OCTOLite 200/300 benchtop video machines from Quality Vision International (QVI) put the benefits of semi-automatic, non-contact video measurement within the reach of virtually any manufacturer, offering a long list of standard features.
- Intuitive metrology software Measure-X® metrology software provides an extensive set of functions for general purpose dimensional measurement.
- Superior optics The precise 6.5 to 1 motorized programmable zoom lens keeps images in focus and on-axis throughout the zoom range. Optional lens attachments can be easily added to expanded the magnification range.
- Mechanical integrity OCTOLite systems include precision mechanical bearing XYZ transports with 1.0 pm linear scales mounted to a stable granite base and column. Manual quick release XY motion controls allow rapid positioning while convenient adjustment knobs provide precise motion. Fine and coarse Z motion adjustment knobs simplify focusing.
- Image processing OCTOLite with Gage-X features full field-of-view image processing with advanced edge detection algorithms designed for real world applications.
OCTO Measuring Range (mm) | ||
---|---|---|
X | Y | Z |
200 | 150 | 150 |
X | Y | Z |
300 | 150 | 150 |
