Download TRP-100

Portable Meter For Temperature/ Humidity/ Differential Pressure/ Dew Point

Description:

The TRP-100-series units are microprocessor based programmable Portable Meter for Temperature, Humidity, Differential Pressure or Dew Point measurement.

Salient Features:

• Automatic recording of Temperature/ Humidity/ Dew point/ Differential pressure as per set time or on key press
• LOW/HIGH (Min / Max), Average value display on LCD
• Configurable alarms with LOW/HIGH SET points along with vibrator, buzzer and LED indication.
• Battery powered with rechargeable battery facility.
• Battery status indication on the LCD display with battery charging LED indication and BAT low indication with Buzzer.
• Password protected function menu.
• Optional data logging facility with 50000 records downloadable with PC software.
• Easy handling and programming with 3 keys and one key for power ON/OFF.
• Small compact & light weight.

Technical Specifications:

• Sensor: Humidity, Temperature and Dew Point Sensor, Built-in different pressure sensor.
• Set Point: Two independent Alarm set points, AL1 & AL2 for Temperature/ Humidity/ Differential Pressure/Dew point with LED indication (Common LEDs);  Integrated Buzzer and Vibrator for Alarm Violation.
• Alarm Logic: High or Low Programmable.
• Setting: Setting by 3 keys on front panel i.e. (SET, SHIFT, INCR).
• LCD: 4×2 digit segmented LCD for display of 2 No parameters among Temperature/Humidity /Differential Pressure/Dew point (selected two Parameter at the time).
• Operating Temp: :   -10 to 55°C
• Storage Temp.:   -10 to 60°C
• Humidity: Below 95% RH, Non condensing.
• Power Supply: Li- polymer, Rechargeable Battery with charger. With 10 Hours of runtime on full charge (with all alarm violation indications i.e. buzzer, vibrator and LEDs)
• Optional Data Logging:-
• Record: 50000 records Logging capacity with data can be visible in ASCII format while downloading in the PC
• Download:  Through USB interface using Terminal
• Enclosure Details:-
• Material: ABS Plastic
• Size: 140mm(L) x 70mm(W) x 30mm(H)
• weight: Approx 210 grams

Applications:

• Pharmaceutical Warehouses
• Shipping containers
• Life Sciences
• Food industry
• Modern Agriculture
• Flowers and Plants
• Breeding Industry
• Cool Cabinets
• Medical Cabinets
• Cold Storage
• Greenhouses
• Oil and Gas flow metering in on-shore, off-share and sub-sea applications.
• Water and effluent treatment plants to monitors filters.
• It is used to monitor sprinkle system.
• HVAC (Heating, ventilation, Air conditioning, Cooling) system to check the filters.
• Duct and pump monitoring.
• Check for leak detection.
