Speed Indicator
Product Details :
MODEL Dimension (HxWxD) mm Panel Cutout (mm) | MSI-1044 MSI-2044 96X96X50 72X72X85 92X92 68X68 |
Display Range INPUT | Upper : 7 segment, 4 digit, 0.56"RED LED display - Meter Per Minute Lower : 7 segment, 4 digit, 0.4", GREEN LED display - Set meter/min |
| Range 0 to 9999 or 0 to 999.9 mpm (Factory set) |
Input Signal SPECIFICATION | NPN / PNP Proximity Switch (Configurable) |
Set Point Dia Entry Setting | 1 or 2 - Set Point (Factory Set) Diameter Range 0 to 999.9 mm By Front Keypad |
Accuracy Power Supply | ±1% of FSD 90 - 270V AC / DC, 50 / 60Hz, SMPS |
Enclosure Material Operating Ambient Temp Relative Humidity OPTIONAI FEATURES | Plastic 0°C - 55°C Upto 95% Non Condensing |
Control Output Relay Ratings SSR / Buzzer Ratio Indicator | 1 - Relay / SSR 1C/O, 5A, 230V AC 12V DC approximately Meter Per Minute / RPM Ratio (Factory Set) 2 NPN / PNP Proximity Switch (Factory Set) |
